CHAPTER 2 CONTROLS AND DISPLAY
Page 2-2
091-00027-001 REV A Evolution Backup Display Pilot’s Guide
Page 2-3
091-00027-001 REV A
Evolution Backup Display Pilot’s Guide
2.1. Controls & Display Orientation
ATTITUDE DISPLAY
16 Attitude Display
17 Aircraft Reference Symbol
19 Roll Pointer
20 Slip/Skid Indicator
21 Altitude Tape
22 Selected Altitude Field (controls the Altitude Bug)
23 Altitude Alerter
24 Numerical Altitude Indication, Altitude Drum/Pointer
25 Altitude Trend Vector
26 Altitude Bug
32 Airspeed Tape
33 Selected Airspeed Field
34 Airspeed Bug
35 Numerical Airspeed Indicator, Airspeed Drum/Pointer
DATA BAR
38 True Airspeed (TAS) or Mach number
39 Barometric Pressure Setting Field
40 Wind Direction and Speed
41 Wind Direction Arrow
42 Outside Air Temperature (OAT)
43 Ground Speed
Table 2-1 EBD Components
CONTROLS
1 Power Button
2 Range Buttons
3 Menu Button
4 Hot Key - Unused
5 Hot Key - Unused
6 360/ARC View
7 Hot Key - Unused
8 BARO
9 Top Knob
10 Top Button
11 Middle Button
12 Bottom Button
13 Bottom Knob
14 Automatic Dimming Photocell
15 microSD Card Slot
NAVIGATION DISPLAY
44 Navigation Display
45 Ownship Symbol
48 Rate of Turn Indicator
49 Ground Track Marker
50 Numerical Direction Indicator
52 Selected Heading Field
53 Heading Bug
57 Vertical Speed Tape
66 Bottom Knob State
67 Top Knob State
68 Hot Key Label
69 Basemap Range
70 Declutter Level
NOTE
Any numbered function omitted from this table is
intentional: the function is not included in the Basic
EBD conguration.
