4.4. Navigation Display
Figure 4-39).
The Direction Indicator comprises a compass, numerical direction indication, heading
bug, Ground Track Marker (when GPS ground track information is available), rate of turn
indicator, and aircraft ownship symbol.
Magnetic Heading Heading Bug
Selected Heading Field Compass Scale
Aircraft Ownship Symbol
Figure 4-39
Horizontal Situation Indicator
