Information
Classification key
DIN EN 1125 panic door locks
The properties of locks are described by the ten-digit classification key according to DIN EN 1125.
Tab. 1 explains the classification key.
Class Meaning
3 High usage frequency in situations when there is little incentive to be careful, thus pos-
ing the possibility of accidents or misuse.
7 200,000 test cycles
6 Door mass up to 200 kg,
B Suitable for use on fire and smoke protection doors on the basis of testing in accord-
ance with EN 1634-1
1 Suitable for critical security function
3 High corrosion resistance in accordance with EN 1670:2007 section 5.6
2 See „DIN EN 179 Notausgangsverschlüsse“, Seite 13, because this standard specifies
higher requirements on intrusion resistance
1
Approved with the following handle bars/ pushbars:
· effeff 8000 – projection of up to 150 mm (vertical projection)
A Panic door lock with handle bar actuation
B Only suitable for installation in single-leaf doors
CE marking
C
ASSA ABLOY
Sicherheitstechnik GmbH
Bildstockstraße 20
72458 Albstadt
GERMANY
0432 - CPD - 0017 2011
DIN EN 1125: 2008-04
376B132 1AB
—
CE documents and further information are available online in the support area
Tab. 1 :
Classification key in
accordance
with DIN EN 1125
