Rotary switch (S2)
Warning!
Danger due to permanently unlocked fire and smoke protection door: A permanently unlocked fire
and smoke protection door is not permissible, because the secure locking function is no longer guaran-
teed with permanent unlocking. The safe function of a fire and smoke protection door must be tested
regularly (“Maintenance”, page80).
Switch
position
Description
0 The lock unlocks as long as the release button is held.
1 to E After the release button has been pressed, the lock unlocks for the time:
· Position 1 2 seconds
· Position 2 4 seconds
· Position 3 6 seconds (factory setting)
· . . .
· Position E 28 seconds
F If the release button is pressed, the lock switches to locking status (toggle function)
Definition of relay positions and LEDs
The relay and the LEDs below them (Pic. 9) have the following meanings (Tab. 6):
!
Tab. 5:
Configuration via rotary
switch
S2
7
6
5
4
3
2
1
0
F
E
D
C
B
A
9
8
Tab. 6 :
Definition of relay
positions and LEDs
Event Relay Status on LED Status
No fire alarm Fire alarm activated LD 1 illumi-
nated
Door locked Locking status activated LD 2 illumi-
nated
Door closed Door status activated LD 3 illumi-
nated
Door handle / profile half cylinder not
actuated
Door handle /
profile cylinder status
lapsed LD 4 dark
No triggering of the swing door drive Door automatics
activation
lapsed LD 5 dark
No alarm / fault Alarm / fault activated LD 6 illumi-
nated
