Installation
Locking cylinders
The length of the locking cylinder to be set is
determined from the door leaf thickness and the
inside and outside door plate thicknesses
(fittings).
The key withdrawal position (Pic. 11) of the
locking lever may not exceed 30° to the bottom
left or right.
Pic. 11 :
Key withdrawal position
max.
30°
max.
30°
