Status query via the UII control module
The UII control module (Universal Interconnectivity Interface) offers several control outputs (Tab. 8). They
are designed as potential-free relay switch-over contacts The control outputs are designed for transmis-
sion of status messages about the motorised multi-point lock 519, the door status and the UII control
module. They can be used to control external devices.
Status output/
control output
Description Description
· nc = normally closed
· no = normally open
Fault / alarm Alarm signal:
· The lock could not lock properly.
· The striking plate was not recognised.
· BMA input alarm message or jumper open.
· External door contact not recognised or jumper open.
· Door remains open for too long in escape door con-
trol unit mode
(Tab. 7, DIP switch).
The alarm is switched off again by pressing the release
button (Tab. 3, Unlocking control input).
· Alarm (nc)
· No alarm (no)
Swing door drive Actuation of the swing door drive; With complete un-
locking of the lock, the output is switched, as a release
signal for a swing door drive (“Configuration of the UII
control module / meaning of the switches”, page64).
· Drive off (nc)
· Drive on (no)
Door handle / profile
cylinder
Status message about the pressed door handle or the
actuated profile cylinder. The query depends on the
configuration of the DIP switch (“Configuration of the UII
control module / meaning of the switches”, page64).
· Not actuated (nc)
· Actuated (no)
Door status OPEN/CLOSED door status message queried by the
internal striking plate sensor. if an external contact is
connected, it is also queried in the OPEN/CLOSED door
status message (“Control via the UII control module”,
page63).
· Open (nc)
· Closed (no)
Locking Status message as to whether the lock is locked or
unlocked.
· Unlocked (nc)
· Locked (no)
Fire alarm Alarm signal: A control signal on the fire alarm system
or the triggering of a smoke detector line (“Control via
the UII control module”, page63) has been received.
The fire protection module (“Electrical accessories”,
page79) can be connected to this output, which
then controls locking of the motorised multi-point lock
519 (“Control via the UII control module”, page63).
· Alarm (nc)
· No alarm (no)
Tab. 8 :
Control outputs of the UII
control module
