Technical data
EN
Electrical specifications, UII module / contact loading capacity of relay outputs
Property
Stabilised rated operating voltage 24 V ± 10 %
100% ED
Rated current consumption for max. 1 second 4 A
Power input
Standby
with UII control module
with UII control module and fire protection module
24 mA
70 mA
90mA
Connecting cable length, with use of
· mains adapter 1003-24-4
(“Electrical accessories”, page79)
10 m with Ø 0.25 mm² + 30 m with Ø
0.8 mm²
