Technical data
Technical specifications
Property
Backset tubular frame
Wooden and steel doors
35 mm, 40 mm, 45 mm ,
55 mm, 65 mm, 80 mm
Centres distance 92 mm
Handle follower 9 mm
Rebate gap 3 mm (2 mm to 5 mm)
Bolt throw 20 mm
Deadbolt height 35 mm
Deadbolt thickness 8 mm
Faceplate dimensions 24 mm x 1760 mm x 6 mm
Striking plate 24 mm x 1760 mm x 6 mm
Material: Latch bolt and dead bolt set
Face plate
Steel
chrome-plated steel
Resistance Intrusion resistance
Deadbolt counterforce
DIN 18251 - class 5
6,000 N
Static latch striking plate stress 5,000 N
Static deadbolt stress 20,000 N
Installation position Vertical
Weight (incl. striking plate, without packaging) 5.1 kg
Protection category (with mounted locking cylinder) IP30
Maximum unlocking time 1 seconds
Unlocking under pre-load with rated operating voltage 50 N
Deadbolt independent when tampered with
Approval for fire doors
Type approval:
Test certificate number:
DO 22.0
P-12000 3555
