Assa Abloy Effeff 519 - Accessories; Striking Plates; Additional Bolt; Space Plate Sets

78
EN
Accessories
Striking plates
The striking plates are available as a 3-piece striking plate, standard striking plate (continuous, Pic. 17) and
striking plate with integrated escape door strike 331U (Pic. 20).
Standard striking plate (continuous)
effeff striking plate, continuous, length 1760 mm, thickness 2 mm, stainless steel 8 1 9 Z B S 1 7 6 2 S B L 0 0
effeff striking plate, continuous, length 1760 mm, thickness 3 mm,
chrome-plated steel 8 1 9 Z B S 1 7 6 3 S B L 0 0
effeff striking plate, continuous, length 1760 mm, thickness 6 mm,
chrome-plated steel 8 1 9 Z B S 1 7 6 6 S B L 0 0
Striking plate with integrated escape door strike 331U
effeff – striking plate, 3 mm, DIN left hand 3 3 1 U 8 0 – 6 0 8 4 8 F 9 4
effeff – striking plate, 3 mm, DIN right hand 3 3 1 U 8 0 – 6 0 8 4 8 F 9 5
effeff – striking plate, 6 mm, DIN left hand 3 3 1 U 8 0 – 6 0 9 4 8 F 9 4
effeff – striking plate, 6 mm, DIN right hand 3 3 1 U 8 0 – 6 0 8 4 8 F 9 5
Loose striking plates prepared for escape door strike 331U
(suitable for multi-point locking systems with latch lock 807-10, Pic. 20)
effeff – striking plate, 3 mm, DIN left hand – – – – – – – 6 0 8 4 8 – 0 4
effeff – striking plate, 3 mm, DIN right hand – – – – – – – 6 0 8 4 8 – 0 4
effeff – striking plate, 6 mm, DIN left hand – – – – – – – 6 0 9 4 8 – 0 4
effeff – striking plate, 6 mm, DIN right hand – – – – – – – 6 0 9 4 8 – 0 4
3-piece striking plate
effeff striking plate, 3-piece length 210/330 mm, thickness 2 mm, stainless steel 8 1 9 Z B S 0 2 1 2 S B L 0 0
effeff striking plate, 3-piece length 210/330 mm, thickness 3 mm,
chrome-plated steel 8 1 9 Z B S 0 2 1 3 S B L 0 0
effeff striking plate, 3-piece length 210/330 mm, thickness 6 mm,
chrome-plated steel 8 1 9 Z B S 0 2 1 6 S B L 0 0
Additional bolt
effeff – additional bolt 270 mm (for door leaf height of 2.16 m or greater) 8 1 9 Z B V 0 2 7 – – – – 0 0
effeff – additional bolt 350 mm (for door leaf height of 2.25 m or greater) 8 1 9 Z B V 0 3 5 – – – – 0 0
effeff – additional bolt 550 mm (for door leaf height of 2.45 m or greater) 8 1 9 Z B V 0 5 5 – – – – 0 0
Space plate sets
effeff – 1 mm spacer plate Order number: 8 1 9 Z B – D 1 – – – – 0 0
effeff – 1 mm spacer plate with latch lock 807 Order number: 8 1 9 Z B – D 1 F – – – 0 0
