Assa Abloy Orion Installation Manual

75
ASSA ABLOY Hospitality
66 8003 016-3
12. Plug the service cable into the
thermostat.
13. Choose the Coordinator tab
and click Get network.
Figure D7
14. Click the plus sign in front of the
thermostat; the motion sensor will
appear in the network tree.
15. Right click on the thermostat to
make sure that is still says 'yes' at
'Join permitted'.
Figure D8
16.Issue a Discovery card in
Visionline:
- Go to Start/Programs/
VisiOnline/VisiOnline and log on.
- Double click on ZigBee
configuration under the Cards
tab in the navigation window.
- Browse to choose a Card holder
and enter No. of days.
- At Type, choose 'Start discovery
in ZigBee'.
- If applicable, tick the checkbox
'Print receipt'.
- Click Make card and present
a card at the encoder.
17.Present the Discovery card at
the lock.
Figure D9
18. In Orion Service, Configure
device section: click Get network
under the Coordinator tab.
Figure D10
