Associated Research OMNIA II 8207 - Page 233

227
DISPLAY AUTO RANGE
Touch Current Display (RMS)
(AC+DC)
Range 1
0.0uA ~ 32.0uA, frequency DC, 15Hz
– 1MHz
Resolution
0.1uA
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10.0uA - 999.9uA)
Range 2
28.0uA ~ 130.0uA, frequency DC,
15Hz - 1MHz
Resolution
0.1uA
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10.0uA - 999.9uA)
Range 3
120.0uA ~ 525.0uA, frequency DC,
15Hz - 1MHz
Resolution
0.1uA
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10.0uA - 999.9uA)
Range 4
400uA ~ 2100uA, frequency DC, 15Hz
- 1MHz
Resolution
1uA
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10uA - 8500uA)
Range 5
1800uA ~ 8400uA, frequency DC,
15Hz - 1MHz
Resolution
1uA
Accuracy
DC , 15Hz < f <100KHz: ±(2% of
reading + 3counts)
100KHz < f < 1MHZ : ±5% of reading
(10uA - 8500uA)
Range 6
8.00mA ~ 10.00mA, frequency DC,
15Hz – 100kHz
Resolution
0.01mA
Accuracy
DC, 15Hz < f < 100KHz : ±5% of
reading (0.01mA -10.00mA )
