Astoria Core 600 - Internal Components

TECHNICIANS' manual 13 of 104
2.9 Internal components
1. Cup warmer heating element
2. Dispensing group
3. Electronic control unit
4. Side LED power supply
5. Side LEDs
6. Electronic control unit
7. Work surface LED
8. Motor pump
9. Drain tray
10. Gas system
11. Static relay
12. Fuses
13. Remote switch
14. Work surface LED power supply
15. Pressure switch
1
15
4
12
14
13
12
32 4 5 2
5
7
8
6
9 7101071011
