TECHNICIANS' manual22 of 104
5.4 Installation and operation spaces
Before the machine arrives, a suitable environment must be
prepared:
• The appliance is not suitable for installation in an area
where a water jet may be used.
• The machine is not suitable for outdoor use.
• The machine must not be used inside kitchens.
• The room must be suited for the intended use with ade-
quate space to comfortably use the machine.
• The lighting must be adequate and conform with current
standards.
• The earthing system must comply with current standards.
• The electrical system must comply with current regula-
tions.
5.5 Support base
To ensure a sufcient degree of ergonomics and machine
safety, a support base with the following features must be
made available (reference drawings on the next page):
• Ensurethatthereissufcientspaceforthemachinetobe
positioned and used correctly.
• The worktop (1) must be comfortable and able to with-
stand the machine’s weight. The height of the upper sec-
tion of the machine (17) must be at least 150 cm from
theoor.
• The base must be perfectly level and have no irregularities.
• The terminals for connecting to the water mains (11) and
electrical mains (8) must be in the immediate vicinity of
the support base;
• The machine can also be positioned against a wall, but
please leave enough space - at least 50 cm (3) - on the
right and left for easy access during cleaning operations.
• Fit a drawer under the worktop (15) which will be used to
depositusedcoffee groundsandifpossible, tarubber
support as well (16)toknockthelterholderagainst.
FOR THE USA: Replace the machine’s feet (7) with
the raised ones supplied.
The new feet must be rmly fastened to the ma-
chine by means of the specic nut.
In order to work properly and ensure safety, the
machine must rest on a perfectly horizontal sur-
face.
Any machine alignment adjustments must be done by ad-
justing the feet (7).
17
5
7
6
8
9
15
16
10
14
13
4
2
1
3
12 11
