Astoria Core 600 - SAE - UL Version Connection

TECHNICIANS' manual 85 of 104
14.9 SAE -UL- version connection
ALD LED power supply
BL Blue
CB Wiring
CO Power switch
F1 10 A fuse
F2 6.3 A fuse
F3
16 A fuse
Class C
GR Grey
GV Yellow green
LA Light ON
MA Brown
MP Motor pump
N Neutral
NE Black
PH1 Phase 1
PH2 Phase 2
PR Pressure switch
R Phase
RE
Heating unit
heating element
RO Red
S Phase
SA
Heating element
protection ther-
mostat
T Phase
F2
F3F3
F1
LA
MP
ALD
BL
RO
RO
BL
CN23
CN22
CN3
CN2
CB
RE
CO
SAPR
PH1
PH2
MA
MA BI
BL
GV
13 9 5
1
3
71115
16 12 8
4
2
610
14
24V
+ -
