Astoria Core 600 - Wiring and Hydraulic Diagrams; Electric Mains and Power Supply Wiring Diagrams

TECHNICIANS' manual 77 of 104
14. WIRING DIAGRAMS
14.1 ELECTRIC MAINS connection
To correctly connect the machine to the electric
mains, please refer to the information provided on
the nameplate (see the example in paragraph 2.7).
R
N
S
N
T
R
S
R
T
CAB
CAB
CAB
5-LEITER-KABEL (3 Phasen+Neutralleiter+Schutzleiter)
4-LEITER-KABEL (3 Phasen+Schutzleiter)
3-LEITER-KABEL (Phase+Neutralleiter+Schutzleiter)
(*) Per il Brasile
BN
BU
GNYE
*BK
*BN
BN GNYEBK BU
BU BK GY
BN
GNYE
R Phase
S Phase
T Phase
N Neutral

Earth
BU Blue
CAB Power cable
GY Grey
GNYE Yellow-green
BN Brown
BK Black
