Astoria Core 600 - Page 89

TECHNICIANS' manual 89 of 104
RO
EVT
SCT
LA
LIV
EVV
EV1
EV3
EV2
MP
EVC
ON/OFF
+24V
CN17
CN18 RS232 MOD-BUS
GND
RX
TX
+24Vcc
Heizelement 2 Boiler
Phase
Neutralleiter
Neutralleiter
VE
BI
CN21
CN19
Phase
CN22
CN23
A2- A1+
L1 T1
Statische Relais
EVM
1
2
3
4
5
6
7
8
9
10
BL
AR
NE
GI
VE
MA
AR
AR Orange
BI White
BL Blue
EV1 GR1 dispensing solenoid valve
EV2 GR2 dispensing solenoid valve
EV3 GR3 dispensing solenoid valve
EV4 GR4 dispensing solenoid valve
EVC
Heating unit lling solenoid
valve
EVM Mixed water solenoid valve
EVT Tea dispensing solenoid valve
EVV Steam dispensing solenoid valve
GI Yellow
LA Cup warmer warning light
LIV Level warning light
MA Brown
MP Motor pump
NE Black
RO Red
SCT Cup warmer heating element
VE Green
