16.2.3 Beverage selection code table
DESCRIPTION SIGNAL RELAY I/O CONNECTOR REF.
1 GR1 Espresso 011 h 1 CN7-1
1 GR1 Medium 012 h 2 CN7-2
1 GR1 Long 013 h 3 CN7-3
2 GR1 Espressos 014 h 4 CN7-4
2 GR1 Medium 015 h 5 CN7-5
2 GR1 Long 016 h 6 CN7-6
1 GR2 Espresso 021 h 7 CN7-7
1 GR2 Medium 022 h 8 CN7-8
1 GR2 Long 023 h 9 CN7-9
2 GR2 Espressos 024 h 10 CN7-10
2 GR2 Medium 025 h 11 CN7-11
2 GR2 Long 026 h 12 CN7-12
1 GR3 Espresso 031 h 13 CN7-13
1 GR3 Medium 032 h 14 CN7-14
1 GR3 Long 033 h 15 CN7-15
2 GR3 Espressos 034 h 16 CN7-16
2 GR3 Medium 035 h 17 CN7-17
2 GR3 Long 036 h 18 CN7-18
1 GR4 Espresso / Cappuccino 041 h 19 CN7-19
1 GR4 Medium / Latte 042 h 20 CN7-20
1 GR4 Long / Frothed milk 043 h 21 CN7-21
2 GR4 Espressos / Warm milk 044 h 22 CN7-22
2 GR4 Medium / Latte Macchiato 045 h 23 CN7-23
2 GR4 Long 046 h 24 CN7-24
Tea 1 051 h 25 CN7-25
Tea 2 052 h 26 CN7-26
CN7-33 I/O enabling
CN7-35 I/O enabling
CN7-37 com. relay
CN7-38 com. relay
