2.1.3. 10) Cycle end
This function enables different cycle ends to be chosen, depending on the configuration
of the instrument (connection to a PLC).
a) Relay sequencing related to different cycle ends
In order to interface the ATEQ F CLASS with its environment (PLC, PC …), the
following timing charts supply the details of the sequencing of the electrical outputs
(relay board on the J3 connector) and pneumatic outputs (automatic connectors),
depending on the commands entered on the front panel or through the J3 connector
(START, RESET).
Legend
A
Wait time for automatic connector A
B
Wait time for automatic connector B
P – F
Pre-Fill time
P – D
Pre-Dump time
F
Fill time
S
Stabilisation time
#
Unspecified time occurring between the programmed test time and
the pressing of the reset
key.
T
Test time
D
Dump time
START
Press the key on the front panel or make a contact between
pins 2-3 on the J3 connector.
RESET
Press the key on the front panel or make a contact between
pins 1-2 on the J3 connector.
Automatic
Connector
Active (high level) : the pneumatic output is active (air output)
Inactive (low level) : the pneumatic output is inactive (no air output)
BP or GP
Bad part or Good part relay on the J3 connector
EoC
End of cycle relay on J3 connector
t mini
Minimum time to accept an entry, 500 ms on connector J8 in the
central module and 50 ms on connector J3 on a head.
Actual times are not those displayed but those on the print-out.
