Atlas Copco HiLight B6+ Kd ESF User Manual

- 95 -
A1 Generator control unit
B7 Fuel level sensor
C10 Capacitor 10µF
D1 Diode
D3 Diode
D4 Diode
E1 Preheat resistor
F10 Fuse 10A DC
F20 Fuse 2A DC - Fleetlink
G1 Battery 12Vdc
G2 Charging regulator
H1 Buzzer
H16 Lamp
K0 Starter solenoid
K1 Preheat relay
K4 Fuel control relay
K5 Starter relay
K100 Remote start relay
K101-K104 Light control relay
K114 Mast down relay
K115 Mast up relay
K116 AC voltage present (230V)
K120 Mains relay
M1 Starter motor
M6 Fuel feed pump
M10 Pump
P7 Photocell
S1 Battery switch
S2 Emergency stop
S9 Low oil pressure switch
S10 GENSET/OFF/MAINS switch
S11 Photocell OFF/ON-switch
S20 REMOTE/OFF/ON switch
S25 Auto positioning switch
S50 Mast up push button
S51 Mast down push button
W10 Spiral cable
X10 Connector wire harness
X11 Auxiliary terminals
X16 Connector lighting
X19 MSA 3P connector
Y10 Mast down solenoid
(03) Optional Mains connection
(04) Optional auto start lighting level
(05) Optional battery switch
(06) Optional override fuel shutdown
(see instruction manual)
(08) Optional MSA connector
(11) Optional Fleetlink
