Atop ABLEPick AT500 - 4.3.20.6 Set Digits brightness

ABLEPick pick-to-light communication protocol
32
00 LED Off
01 LED On
02 2 sec blinking
03 1 sec blinking
04 0.5 sec blinking
05 0.25 sec blinking
For AT7XX series (V1.1),
CCB LEN (L) = 0CH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1F H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
DATA[0] = 05H
DATA[1] = 00H
DATA[2] = time interval
DATA[3] = time interval
DATA[4] = time interval
DATA[2~4] = Blinking Period
Blinking Period: each 4 bits represent one digit blinking period value.
DATA[2] bit4 ~ bit7 = 6
th
digit
DATA[2] bit0 ~ bit3 = 5
th
digit
DATA[3] bit4 ~ bit7 = 4
th
digit
DATA[3] bit0 ~ bit3 = 3
rd
digit
DATA[4] bit4 ~ bit7 = 2
nd
digit
DATA[4] bit0 ~ bit3 = 1
st
digit
00 LED Off
01 LED On
02 2 sec blinking
03 1 sec blinking
04 0.5 sec blinking
05 0.25 sec blinking
For example :
DATA[2] = 52H : means 6
th
digit blink by 0.25 sec interval, 5
th
digit by 2 sec.
DATA[3] = 34H : means 4
th
digit blink by 1 sec interval, 3
rd
digit by 0.5 sec.
DATA[4] = 10H : means 2
nd
digit blink by solid on, 1
st
digit is off
4.3.20.6 Set Digits brightness
CCB LEN (L) = 0AH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1F H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
