ABLEPick pick-to-light communication protocol
33
DATA[0] = 06H
DATA[1] = time interval
DATA[1] = Digit Brightness
Digit Brightness: Setting each digit brightness while it change to be dark with
blinking.
Bit = 1: brightness 50 %, bit = 0: light off
Bit0: represents digit0
Bit1: represents digit1
Bit2: represents digit2
Bit3: represents digit3
Bit4: represents digit4
Bit5: represents digit5
Bit6: no used
Bit7: no used
4.3.20.7 Configure Special function
For configuring some special function
CCB LEN (L) = 0AH
Data length of this block
CCB LEN (H) = 00H
MESSAGE TYPE = 60H
60H : port 1
Reserved
Reserved
Reserved
SUB-COMMAND = 1F H
SUB-NODE = {01H ~ FAH}
0x01~0xFA (address)
or 0xFC (Broadcasting)
DATA[0] = 0AH
DATA[1] = Configuration
DATA[1] =
Bit0: selecting Picking mode 1-stock/0-picking
Bit1: stock mode quick completion enable/disable
Bit2: Completion mark ”-------“ display enable/disable
Bit3: device self-testing function enable/dispable
Bit4: Cycle edit function enable/disable
Bit5: no used
Bit6: no used
Bit7: no used
Note (1) : Bit 0, selecting pick mode.
configure the light to be stock mode or pick mode, same as sub-command 19H
& 1AH.
Note (2) : Bit 1 : stock mode quick completion.
When configure device to be "stock mode", after sending number on display,
user needs to follow left to right sequence, digit by digit to adjust the quantity
and confirm back, even quantity no need to adjust, this procedure also needs to
go through to confirm. "Stock mode quick completion" can skip this procedure to
confirm quickly if there is no any change on digits under stock mode, just push
the button to confirm back. Under this configuration, if user needs to adjust the
quantity, just push the down-count/up-count button instead, then it will enter the
original procedure to adjust each digit
Note (3) : Bit 2 : Completion mark “-----“ display
