Reading measured value block
Enter display group number XXX
- Enter display group number.
Notes:
◆ The next display group can be selected by pressing the "3" key; to switch back to the previous display group
press "1".
◆ If all the display zones show the specified values:
- Press the ⇒ key.
-> Indicated on display:
Rapid data transfer HELP
Select function XX
List of available group numbers
Notes:
◆ The vent temperature sender -G191 is additionally installed in vehicles with map-controlled cooling; the
value measured is displayed in display zone 1 of display group 007.
◆ Display zone 4 in display group 009 is only occupied for operating and display units -E87 with two displays
only in models with part number 8L0 820 043 and indices "M" and "N".
Display group no. Display zone Designation Details on page
001 1 Compressor shutoff criteria 34
2 Operating and display unit -E87 with two displays
Voltage for magnetic clutch -N25.
Operating and display unit -E87 with one display
Voltage, terminal "15" in V.
3 Operating and display unit -E87 with two displays
Voltage, terminal "15" in V.
Operating and display unit -E87 with one display
Signal for "ignition off time" (standing time) in minutes.
Display group no. Display zone Designation Details on page
001
4 Operating and display unit -E87 with two displays
Signal for "ignition off time" (standing time) in minutes.
34
Operating and display unit -E87 with one display
Not used
002 1-4 Temperature flap positioning motor -V68 37
003 1-4 Central flap positioning motor -V70 37
004 1-4 Footwell/defroster flap positioning motor -V85 38
005 1-4 Air flow flap positioning motor -V71. 38
006 1 Calculated ambient temperature (for ambient temperature
indicator -G106)
38
2 Temperature sensor for fresh air intake duct -G89
3 Ambient temperature sensor -G17
4 Sunlight penetration photo sensor-G107
Audi A3 1997 ➤
Heating, Air Conditioner - Edition 06.2000
32 01 - Self-diagnosis, Electrical check
