Display group no. Display zone Designation Details on page
007 1 Centre vent temperature sender -G191
Sender -G191 is not installed in vehicles without map-con‐
trolled cooling.
Sender -G191 is only available in vehicles with map-control‐
led cooling.
39
2 Footwell vent temperature sender -G192
3 Dash panel temperature sensor -G56
4 Refrigerant temperature
008 1 Specified voltage at fresh air blower -V2 40
2 Actual voltage at fresh air blower -V2
3 Lighting displays (terminal 58d)
4 Operating and display unit -E87 with two displays
Side lights (terminal 58 or 58s)
Operating and display unit -E87 with one display
Lighting switch (terminal 58s)
Display group no. Display zone Designation Details on page
009 1 Engine speed 41
2 Vehicle speed
3 Operating and display unit -E87 with two displays
Auxiliary heater
Operating and display unit -E87 with one display
Side lights (terminal 58)
4 Operating and display unit up to index "E" (with two displays)
Display zone vacant (disregard display).
Operating and display unit with indices "M" or "N" (two dis‐
plays)
Assignment of ignition key
Operating and display unit with one display.
Auxiliary heater
Display group no. Display zone Designation Details on page
010 1 Signal from dash panel insert for refrigerant temperature "too
high"
43
2 Air conditioner compressor cut-in
3 Air conditioner pressure switch -F129 / high-pressure sensor
-G65
4 Operating and display unit with two displays.
Vacant
Operating and display unit with one display.
Actuation for heated rear window
Display group no. Display zone Designation Details on page
011 1 ... 4 The last four compressor shut-off criteria which were effec‐
tive for longer than 20 seconds.
45
012 1 Increase in idle speed 45
2 Actuation of two-way valve for refrigerant shut-off valve -
N147
3 Sender for outlet temperature -G263
The sender -G263 is not installed into the Audi A3 at the
moment, ignore display.
