Part names and functions
13
6
Display
Shows the current status.
If no buttons are pressed for a period of 30seconds, the display will turn off. When the display turns off, press the
power button to turn it back on.
7
Power button
Turns the device on/off and performs pairing.
ATW-T1407
1
2
6 74 5 3
1
USB port (USB Type-C)
Use this port when charging the device and when updating the firmware.
2
Status indicator lamp
Lights when the device is on. This lamp also shows the status of this transmitter. Refer to "Indicator lamps" (p. 73)
for details.
3
Input connector
Use to connect a gooseneck microphone.
4
Talk switch
Switches between muted and unmuted.
5
Talk indicator lamp
Shows the muted/unmuted status. Refer to "Indicator lamps" (p. 73) for details.
