AudioCodes Mediant 1000 User Manual

Version 7.2 1193 Mediant 1000B Gateway & E-SBC
User's Manual 64. Technical Specifications
Function Specification
3 parameters
Redundancy
Detection of proxy failures and subsequent routing to alternative
proxies
Routing Features
Least-cost routing, call forking, load balancing, E911 gateway
support, emergency call detection and prioritization
Management
OAM&P
Browser-based GUI, CLI, SNMP, EMS, INI Configuration file, REST
API
OSN Server Platform (Optional)
Single Chassis Integration
Embedded, Partner Application Platform for third-party services
Memory
Up to 8 GB RAM
Storage
HDD or SDD
Physical / Environmental
Dimensions
1U x 320 mm x 345 mm (HxWxD)
Weight
Approx. 5.95lb (2.7kg) installed with OSN
Mounting
Desktop or 19" mount
Power
Single universal power supply 100-240 VAC, 50-60 Hz, 1.5A max. or
optional redundant power supply
Environmental
 Operational: 0 to 40°C (32 to 104°F)
 Storage: -20 to 70°C (-4 to 158°F)
 Relative Humidity: 10 to 85% non-condensing

AudioCodes Mediant 1000 Specifications

General

Data link protocols	CAS: MF-R1: T1 CAS, ISDN PRI: ETSI/EURO ISDN, ANSI NI2, QSIG
Security algorithms	HTTPS, SRTP
Authentication method	RADIUS
Internal memory	512 MB
Built-in processor	Celeron 600 MHz
Processor frequency	600 MHz
Internal memory type	-
Number of processors installed	1
Voice codecs	G.711, G.723.1, G.726, G.729A, iLBC
Safety	UL60950-1, FCC 47 CFR
Certification	ETS 300019-2-1, ETS 300019-2-2 ETS 300019-2-3
Mounting type	Rack mounting
LED indicators	Yes
Power requirements	90-260 V AC

Weight and Dimensions

Size (imperial)	19 \
