Version 7.2 41 Mediant 1000B Gateway & E-SBC
User's Manual 4. Configuring VoIP LAN Interface for OAMP
4.2 CLI
This procedure describes how to configure the VoIP-LAN IP address for OAMP through the
device's CLI. The procedure uses the regular CLI commands. Alternatively, you can use
the CLI Wizard utility to set up your device with the initial OAMP settings. The utility
provides a fast-and-easy method for initial configuration of the device through CLI. For
more information, refer to the CLI Wizard User's Guide.
 To configure the OAMP IP address through CLI:
1. Connect the RS-232 port of the device to the serial communication port on your
computer. For more information, refer to the Hardware Installation Manual.
2. Establish serial communication (e.g., telnet) with the device using a terminal emulator
program such as HyperTerminal, with the following communication port settings:
• Baud Rate: 115,200 bps
• Data Bits: 8
• Parity: None
• Stop Bits: 1
• Flow Control: None
3. At the CLI prompt, type the username (default is "Admin" - case sensitive):
Username: Admin
4. At the prompt, type the password (default is "Admin" - case sensitive):
Password: Admin
5. At the prompt, type the following:
enable
6. At the prompt, type the password again:
Password: Admin
7. Access the Network configuration mode:
# configure network
8. Access the IP Interfaces table:
(config-network)# interface network-if 0
9. Configure the IP address:
(network-if-0)# ip-address <IP address>
