AudioCodes Mediant 1000

Version 7.2 241 Mediant 1000B Gateway & E-SBC
User's Manual 15. Services
3. Click New; the following dialog box appears:
Figure 15-22: Management LDAP Groups Table - Add Dialog Box
4. Configure a group name(s) with a corresponding access level according to the
parameters described in the table below.
5. Click Apply, and then save your settings to flash memory.
Table 15-10: Management LDAP Groups Table Parameter Descriptions
Parameter Description
Index
[MgmntLDAPGroups_GroupIndex]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Level
level
[MgmntLDAPGroups_Level]
Defines the access level of the group(s).
 [0] Monitor (Default)
 [1] Admin

[2]
Security Admin
Groups
groups
[MgmntLDAPGroups_Group]
Defines the attribute names of the groups in the LDAP server.
The valid value is a string of up to 256 characters. To define
multiple groups, separate each group name with a semicolon (;).
15.3.8 Configuring the Device's LDAP Cache
The device can optionally store LDAP queries of LDAP Attributes for a searched key with
an LDAP server and the responses (results) in its local cache. The cache is used for
subsequent queries and/or in case of LDAP server failure. The benefits of this feature
include the following:

Improves routing decision performance by using local cache for subsequent LDAP
queries

Reduces number of queries performed on an LDAP server and corresponding
bandwidth consumption

Provides partial survivability in case of intermittent LDAP server failure (or network
isolation)
