AudioCodes Mediant 1000 User Manual

Version 7.2 851 Mediant 1000B Gateway & E-SBC
User's Manual 54. Reporting Information to External Party
CDR Field Title
Source URI Before Manipulation SrcURIBeforeMap
Destination URI DstURI
Destination URI Before Manipulation DstURIBeforeMap
Call Duration Durat
Termination Side TrmSd
Termination Reason TrmReason
Termination Reason Category TrmReasonCategory
Setup Time SetupTime
Connect Time ConnectTime
Release Time ReleaseTime
Redirect Reason RedirectReason
Redirect URI RedirectURINum
Redirect URI Before Manipulation RedirectURINumBeforeMap
Signaling IP DiffServ TxSigIPDiffServ
IP Group Name IPGroup
SRD Name SrdId
SIP Interface Name SIPInterfaceId
Proxy Set Name ProxySetId
IP Profile Name IpProfileId
Media Realm Name MediaRealmId
Direct Media DirectMedia
SIP Termination Reason SIPTrmReason
SIP Termination Description SIPTermDesc
Caller Display ID Caller
Callee Display ID Callee
54.2.1.4 CDR Fields for Gateway Application
The CDRs generated by the device for Gateway calls include media and signaling CDR
fields. The default CDR fields are listed in the table below.
The CDR can be one of the following report types (GWReportType field), depending at
which stage of the SIP dialog it was sent:

"CALL_START": CDR is sent upon an INVITE message.

"CALL_CONNECT": CDR is sent upon a 200 OK response (i.e., call is established).

"CALL_END": CDR is sent upon a BYE message (i.e., call ends).

AudioCodes Mediant 1000 Specifications

General

Data link protocols	CAS: MF-R1: T1 CAS, ISDN PRI: ETSI/EURO ISDN, ANSI NI2, QSIG
Security algorithms	HTTPS, SRTP
Authentication method	RADIUS
Internal memory	512 MB
Built-in processor	Celeron 600 MHz
Processor frequency	600 MHz
Internal memory type	-
Number of processors installed	1
Voice codecs	G.711, G.723.1, G.726, G.729A, iLBC
Safety	UL60950-1, FCC 47 CFR
Certification	ETS 300019-2-1, ETS 300019-2-2 ETS 300019-2-3
Mounting type	Rack mounting
LED indicators	Yes
Power requirements	90-260 V AC

Weight and Dimensions

Size (imperial)	19 \
