User's Manual 566 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Note:
• If you have configured regular Tel-to-IP or IP-to-Tel manipulation rules (see
''Configuring Source/Destination Number Manipulation'' on page 503), the device
applies them before applying the local-global mapping rules configured in the
table.
• To allow the end user to hear a dial tone when picking up the BRI phone, it is
recommended to set the Progress Indicator in the Setup Ack bit (0x10000=65536).
Therefore, the recommended value is 0x10000 + 0 x1000 = 65536 + 4096 =
69632 (i.e., set the ISDNInCallsBehavior parameter to 69632).
The following procedure describes how to configure the Supplementary Services table
through the Web interface. You can also configure it through ini file (ISDNSuppServ) or CLI
(configure voip > gateway digital isdn-supp-serv).
 To configure endpoint supplementary services:
1. Open the Supplementary Services table (Setup menu > Signaling & Media tab >
Gateway folder > DTMF & Supplementary > Supplementary Services).
2. Click New; the following dialog box appears:
Figure 26-12: Supplementary Services Table - Add Dialog Box
3. Configure a supplementary service according to the parameters described in the table
below.
4. Click Apply.
The figure below displays an example of multiple-line extensions configured in the
Supplementary Services table:
Figure 26-13: Supplementary Services Table Page
You can also register and un-register an endpoint configured in the table:
To Next Page
