Page 3–12 Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Chapter 3: Configuration and Parameters
Summary – Parameters for Touchscreen Setup – “Log” Category (continued)
– Group Parameter Units Range
Read /
Write
Modbus
Default
Setting
User
Setting
Address Hex
Category – Log
(P19)
Stop Current Log
[detailed info
starts page 3–68]
P19�0 – Last Peak Stop Current A 0 to 10,000 Read 39040 9880 0 –
P19�1 – Last Peak Stop Current -1 A 0 to 10,000 Read 39042 9882 0 –
P19�2 – Last Peak Stop Current -2 A 0 to 10,000 Read 39044 9884 0 –
P19�3 – Last Peak Stop Current -3 A 0 to 10,000 Read 39046 9886 0 –
P19�4 – Last Peak Stop Current -4 A 0 to 10,000 Read 39048 9888 0 –
P19�5 – Last Peak Stop Current -5 A 0 to 10,000 Read 39050 988A 0 –
P19�6 – Last Peak Stop Current -6 A 0 to 10,000 Read 39052 988C 0 –
P19�7 – Last Peak Stop Current -7 A 0 to 10,000 Read 39054 988E 0 –
P19�8 – Last Peak Stop Current -8 A 0 to 10,000 Read 39056 9890 0 –
P19�9 – Last Peak Stop Current -9 A 0 to 10,000 Read 39058 9892 0 –
(P20)
Temperature Log
[detailed info
starts page 3–71]
P20�0 – Last Temperature °C -20°C to 80°C Read 39680 9B00 ambient –
P20�1 – Last Temperature -1 °C -20°C to 80°C Read 39681 9B01 ambient –
P20�2 – Last Temperature -2 °C -20°C to 80°C Read 39682 9B02 ambient –
P20�3 – Last Temperature -3 °C -20°C to 80°C Read 39683 9B03 ambient –
P20�4 – Last Temperature -4 °C -20°C to 80°C Read 39684 9B04 ambient –
P20�5 – Last Temperature -5 °C -20°C to 80°C Read 39685 9B05 ambient –
P20�6 – Last Temperature -6 °C -20°C to 80°C Read 39686 9B06 ambient –
P20�7 – Last Temperature -7 °C -20°C to 80°C Read 39687 9B07 ambient –
P20�8 – Last Temperature -8 °C -20°C to 80°C Read 39688 9B08 ambient –
P20�9 – Last Temperature -9 °C -20°C to 80°C Read 39689 9B09 ambient –
(P21)
Overload Log
[detailed info
starts page 3–75]
P21�0 – Last Overload % 0 to 100 Read 40320 9D80 0 –
P21�1 – Last Overload -1 % 0 to 100 Read 40321 9D81 0 –
P21�2 – Last Overload -2 % 0 to 100 Read 40322 9D82 0 –
P21�3 – Last Overload -3 % 0 to 100 Read 40323 9D83 0 –
P21�4 – Last Overload -4 % 0 to 100 Read 40324 9D84 0 –
P21�5 – Last Overload -5 % 0 to 100 Read 40325 9D85 0 –
P21�6 – Last Overload -6 % 0 to 100 Read 40326 9D86 0 –
P21�7 – Last Overload -7 % 0 to 100 Read 40327 9D87 0 –
P21�8 – Last Overload -8 % 0 to 100 Read 40328 9D88 0 –
P21�9 – Last Overload -9 % 0 to 100 Read 40329 9D89 0 –
(P22)
Totals Log
[page 3–77]
P22�0 – Number of Starts – 0 to 4,294,836,225 Read 35840 8C00 0 –
(P23)
[page 3–77]
P23�0 – Download Log File – – R/W n/a n/a –
(P24)
[page 3–77]
P24�0 – Clear Trip Log – – R/W n/a n/a –
