1.2
Ordering information
Control phase
Item
Rated current
capacity
Size
Power supply
Option
DPU
Digital Power Controller Unit
R
RS485 communication
D
Remote Display Unit
A
Remote Display Unit
+ RS485 communication
N
No option
1
110VAC
2
220VAC
3
380VAC
4
440VAC
1
Single-phase
3
3-phase
Single-phase
3-phase
A
0 to 70A
0 to 50A
B
80 to 200A
70 to 200A
C
250 to 350A
D
400 to 600A
E
Option
025
25A
200
200A
040
40A
250
250A
050
50A
350
350A
070
70A
400
400A
080
80A
500
500A
100
100A
600
600A
120
120A
150
150A
180
180A
1
2
A
DPU
025
R
9
11
Table of Contents
User Manual Guide
4
User Manual Symbols
5
Safety Considerations
6
Table of Contents
7
Table of Contents
8
Product Introduction
9
Features
9
Ordering Information
10
Unit Description
11
Specifications
13
Connections
20
Single-Phase (DPU1 Series)
20
3-Phase (DPU3 Series)
22
Installation and Initial Operation
24
Installation
24
Initial Display
24
Parameter Setting Group
24
Parameters
24
Monitoring Mode
25
Operation Mode [ OP ]
26
Setting Mode 1 [ ST-1 ]
27
Setting Mode 2 [ ST-2 ]
28
Parameter Setting and Functions
30
Control Input
30
Functions
31
Control Method [ C-MD ]
31
Soft Start [ ST-T ]
34
Start Limit [ S-LM ] and Start Limit Time [ S-LT ]
35
Output Slope Setting [ SLOP ]
35
Output Slope Manual Adjustment [ A-GA ]
36
Base-Up [ B-UP ]
36
Slow Up/Slow down [ UP-T / DN-T ]
37
Output High Limit Value [ H-OL ], Output Low Limit Value [ L-OL ]
37
Digital Input (DI)
38
Proportional and Integral Constant Set of Feedback Control
40
Input Correction[ IN-B ]
41
Input Slope Correction [ SPAN ]
41
Display Value Content [ DISP ], Bar Graph Content [ BAR ]
41
Load Resistance Display Method [ DRES ]
42
Full Load Auto Recognition [ F-LD ]
43
Parameter Lock [ LOCK ]
43
Alarm
44
Overcurrent Alarm [ OC-A ]
44
Current Limit [ C-LM ]
44
Overvoltage Alarm [ OV-A ]
45
Fuse Disconnection Alarm [ FUSE ]
45
Heatsink Overheating Alarm [ HEAT ]
45
Element Error Alarm [ SCR ]
45
Heater Disconnection Alarm [ HB-A ]
46
Factory Default
48
Maintenance
50
Fuse
50
Single-Phase (DPU1 Series)
50
3-Phase (DPU3 Series)
51
Thyristor (SCR)
51
Modbus Mapping Table
52
Function Code 3 (0×03) = Read Holding Resisters
52
Function Code 4 (0×04) = Read Input Resisters
52
Function Code 6 (0×06) = Write Single Resisters
53
Function Code 16 (0×10) = Write Multiple Resisters
53
Address Mapping Table
54
Input Resisters
54
Holding Resisters
56
Other manuals for Autonics DPU Series
Manual
22 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Autonics DPU Series and is the answer not in the manual?
Ask a question
Autonics DPU Series Specifications
General
Brand
Autonics
Model
DPU Series
Category
Controller
Language
English
