4. Connections
22
© Copyright Reserved Autonics Co., Ltd.
-|Transparent setting guide|-
4. Connections
4.1 Single-phase (DPU1 series)
● A Size ● B Size
R S U F.G.
R S U F.G.
Internal adjuster(10kΩ)
3-level slide
switch
● C Size ● D Size
R SU F.G.
R S U F.G.
