Autonics DPU Series User Manual

2. Specications
15
© Copyright Reserved Autonics Co., Ltd.
-|Transparent setting guide|-
2. Specications
Series
DPU1 DPU3
Control phase Single-phase 3-phase
Power supply
110VAC
ᜠ
/220VAC
ᜠ
/380VAC
ᜠ
/440VAC
ᜠ
(
FAN and control power 220VAC
ᜠ
50/60Hz separately)
Allowable voltage 90 to 110% of rated voltage 85 to 115% of rated voltage
Rated frequency 50/60Hz (auto recognition), allowable frequency range: ±2Hz
Min. load current 1A
Output range Phase control: 0 to 98%, Z.C. control: 0 to 100%
Control method
※
1
• Phase control
:
Normal control (Non-Feedback), constant voltage/constant current/constant power control
(Feedback)
• Cycle control (Z.C.): Fixed cycle control, variable cycle control
• ON/OFF control (Z.C.)
Load
• Phase control: resistance load, inductive load
• ON/OFF, Cycle control: resistance load
Power consumption Max. 7W (except FAN operation power) Max. 10W (except FAN operation power)
Display method
• Display value and SV display
: 7-segment 4 digit
• Status display: 4 LED
•
Display value percentage display: 11 LED Bar
• Display value and SV display
: 7-segment 4 digit
• Status display: 6 LED
• Display value percentage display: 11 LED Bar
Output accuracy
• Constant voltage feedback control
: Within ±3% F.S. of rated voltage (within variable ±10% F.S. of rated voltage)
• Constant current feedback control
: Within ±3% F.S. of rated voltage (within variable 1 to 10 times of rated resistance)
• Constant power feedback control
: Within ±3% F.S. of rated voltage (within variable ±10% F.S. of rated voltage and within
variable 1 to 10 times of rated resistance)
• Normal control: within ±10% F.S. of rated voltage
Set method By front keys, by communication
Control input
• Auto:
4-20mA / 0-20mA / 0-5VDC
ᜡ
/ 1-5VDC
ᜡ
/ 0-10VDC
ᜡ
/ voltage
pulse(0/12VDC
ᜡ
(24VDC
ᜡ
)) / no-voltage input (ON/OFF) / communication input(RS485)
• Manual: inside 10kΩ adjuster, outside 3 to 10kΩ adjuster (min. 2W)
Digital input(DI) AUTO/MAN switching, RUN/STOP switching, RESET, Output holding, SP setting (SP1 to 6)
Display content
Control input, load voltage, load current, load power, load resistance, power supply frequency
Min. display output Min. 2.5% of rated voltage/current
Option output RS485 communication output (Modbus RTU method), [max. 32 units]
Dielectric strength 2,000VAC 50/60 Hz for 1 min (between input terminal and power terminal)
Vibration
0.75mm amplitude at frequency of 5 to 55Hz (for 1 min) in each of X, Y, Z directions for 2 hours
Insulation resistance Over 200MΩ(at 500VDC megger)
Noise immunity ±2kV the square wave noise (pulse width 1㎲) by the noise simulator
Environ
ment
Ambient temp. 10 to 50℃, storage: 20 to 80℃
Ambient humi. 5 to 90%RH
,
storage: 5 to 90%RH
Approval
ᜢ
Weight
※
2
• A size
: Approx. 3.2kg
(approx. 3.0kg)
• C size
: Approx. 12.1kg
(approx. 11.0kg)
• B size
: Approx. 5.6kg
(approx. 3.0kg)
• D size
: Approx. 19.3kg
(approx. 11.0kg)
• A size
: Approx. 7.6kg
(approx. 6.5kg)
• C size
: Approx. 21.1kg
(approx. 20.0kg)
• B size
: Approx. 13.0kg
(approx. 11.5kg)
• Approx. size
: Approx. 35.7kg
(approx. 30.8kg)
※1. Variable cycle control is only for single-phase model.
※
2. The weight includes packaging. The weight in parenthesis is for unit only.
※
Environment resistance is rated at no freezing or condensation.
