9. Modbus Mapping Table
58
© Copyright Reserved Autonics Co., Ltd.
-|Transparent setting guide|-
9.5.2 Holding resisters
(1) Single-phase (DPU1 series)
No. (Address) Item Factor
400001 (0000) Reference Value
- *0.1 (0 to 1000)
400002 (0001) Start Limit Time
S-LT
0 to 100
400003 (0002) Start Limit
S-LM
*0.1 (0 to 1100)
400004 (0003) Soft Start Time
ST-T
0 to 100
400005 (0004) Output High-Limit
H-OL
*0.1 (0 to 1100)
400006 (0005) Output Low-Limit
L-OL
*0.1 (0 to 1100)
400007 (0006) Remote SP1
SP1
*0.1 (0 to 1000)
400008 (0007) Remote SP2
SP2
*0.1 (0 to 1000)
400009 (0008) Remote SP3
SP3
*0.1 (0 to 1000)
400010 (0009) Remote SP4
SP4
*0.1 (0 to 1000)
400011 (000A) Remote SP5
SP5
*0.1 (0 to 1000)
400012 (000B) Remote SP6
SP6
*0.1 (0 to 1000)
400013 (000C) Slow Up Time
UP-T
0 to 999
400014 (000D) Slow Down Time
DN-T
0 to 999
400015 (000E) Current Limit
C-LM
*0.1 (0 to 1100)
400016 (000F) Over current value
OC-V
*0.1 (0 to 1200)
400017 (0010) Over current time
OC-T
0 to 100
400018 (0011) Over voltage value
OV-V
*0.1 (0 to 1200)
400019 (0012) Over voltage time
OV-T
0 to 100
400020 (0013) Load detector alarm value
HB-V
*0.1 (100 to 5000)
400021 (0014) Display selected contents
DISP
0 to 3
0:
LD-V
, 1:
AMP
,
2:
KW
, 3:
REF
400022 (0015) Bar graph's content
BAR
0 to 3
0:
LD-V
, 1:
AMP
,
2:
KW
, 3:
REF
400023 (0016) Control integer KP value
P
1 to 2000
400024 (0017) Control integer KI value
I
*0.1 (1 to 9999)
400025 (0018) Control Method
C-MD
0 to 6
0:
F-CY
, 1:
V-CY
,
2:
ONOF
, 3:
PA
, 4:
V-FB
,
5:
C-FB
, 6:
W-FB
400026 (0019) Digital input 1
DI-1
0 to 5
400027 (001A) Digital input 2
DI-2
0:
SP M
, 1:
SP1
,
2:
SP2
, 3:
SP3
,
4:
RST
, 5:
HOLD
400028 (001B) Digital input 3
DI-3
