Autonics DPU Series - Function Code 4: Read Input Registers

9. Modbus Mapping Table
57
© Copyright Reserved Autonics Co., Ltd.
-|Transparent setting guide|-
(2) 3-phase (DPU3 series)
Address Item Factor
300001(0000) Load voltage between U-V line (Vrms) *0.1
300002(0001) Load voltage between V-W line (Vrms) *0.1
300003(0002) Load voltage between W-U line (Vrms) *0.1
300004(0003) Load current of U-phase (Arms) *0.1
300005(0004) Load current of V-phase (Arms) *0.1
300006(0005) Load current of W-phase (Arms) *0.1
300007(0006) Power *0.01
300008(0007) Load resistance (% display for initial load) *0.1
300009(0008) Power frequency *0.01
300101(0064) Product number H 00
300102(0065) Product number L 00
300103(0066) Hardware version 10
300104(0067) Software version 10
300105(0068) Model name 1 "DP"
300106(0069) Model name 2 "2-"
300107(006A) Model name 3 "00"
300108(006B) Model name 4 " "
300109(006C) Model name 5 " "
300110(006D) Model name 6 " "
300111(006E) Model name 7 " "
300112(006F) Model name 8 " "
300113(0070) Model name 9 " "
300114(0071) Model name " "
300115(0072) Reserved Reserved
300116(0073) Reserved Reserved
300117(0074) Reserved Reserved
300118(0075) Coil start address 0
300119(0076) Coil quantity 0
300120(0077) Input start address 0
300121(0078) Input quantity 0
300122(0079) Holding reg start address 0
300123(007A) Holding reg quantity 32
300124(007B) Input reg start address 0
300125(007C) Input reg quantity 5
