9. Modbus Mapping Table
56
© Copyright Reserved Autonics Co., Ltd.
-|Transparent setting guide|-
9.5 Address mapping table
9.5.1 Input resisters
(1) Single-phase (DPU1 series)
No.(address) Item Factor
300001(0000) Output voltage *0.1
300002(0001) Load current *0.1
300003(0002) Power *0.1
300004(0003) Load resistance *0.1
300005(0004) Power frequency *0.01
300101(0064) Product number H 00
300102(0065) Product number L 00
300103(0066) Hardware version 10
300104(0067) Software version 10
300105(0068) Model name 1 "DP"
300106(0069) Model name 2 "2-"
300107(006A) Model name 3 "00"
300108(006B) Model name 4 " "
300109(006C) Model name 5 " "
300110(006D) Model name 6 " "
300111(006E) Model name 7 " "
300112(006F) Model name 8 " "
300113(0070) Model name 9 " "
300114(0071) Model name 10 " "
300115(0072) Reserved Reserved
300116(0073) Reserved Reserved
300117(0074) Reserved Reserved
300118(0075) Coil start address 0
300119(0076) Coil quantity 0
300120(0077) Input start address 0
300121(0078) Input quantity 0
300122(0079) Holding reg start address 0
300123(007A) Holding reg quantity 32
300124(007B) Input reg start address 0
300125(007C) Input reg quantity 5
