Dimensions
19
© Copyright Reserved Autonics Co., Ltd.
-|Transparent setting guide|-
(2) B Size: DPU3 B - 070 / 080 / 100 / 120 / 150 / 180 / 200
176
217
185.6
160°
366
278
195
213
40 200
367
3.5 40 280 40
126
4-Ø7
(3) C Size: DPU3 C - 250 / 350
173
227.5
252.6
497
160°
311
261
278
40 200
457
125
280
45
85
3.3
45
85
4-Ø7
