Autonics DPU Series User Manual

6. Parameter Setting and Functions
41
© Copyright Reserved Autonics Co., Ltd.
-|Transparent setting guide|-
• Single SP [
SP-1
,
SP-2
,
SP-3
]
For single SP, set
SP-1
,
SP-2
,
SP-3
to each digital input for output to reach to the relevant SP.
It is available to set individually and duplicated and it is relevant with setting point [
SP1
to
SP3
].
• Multi SP [
SP M
]
It is available to set total 6 SPs and to control output depending on 3 digital inputs’ setting.
This function is selectable only in [
DI-1
]. When selecting [
SP M
] at [
DI-1
], [
DI-2
,
DI-3
]
parameters are not displayed.
When selecting [
SP M
] at [
DI-1
], 6 parameters to set SPs are displayed in operating mode.
(
SP1
,
SP2
,
SP3
,
SP4
,
SP5
,
SP6
)
※
A, B, C, D, E, F
: Close/Open status of Digital Input
Output
(%)
DI-1 DI-2 DI-3
Operating mode SP value set parameter
SP1 SP2 SP3
SP1 (e.g.: 20%)
SP2 (e.g.: 40%)
SP3 (e.g.: 60%)
A: DI-1 is ON
B: DI-2 is ON
C: DI-3 is ON
Output
(%)
DI-1 DI-2 DI-3
Operating mode SP value set parameter
A
○ X X
SP1 (e.g.: 20%)
B
X ○ X
SP2 (e.g.: 40%)
C
○ ○ X
SP3 (e.g.: 60%)
D
X X ○
SP4 (e.g.: 80%)
E
○ X ○
SP5 (e.g.: 100%)
F
X ○ ○
SP6 (
e.g.
: 0%)
G
○ ○ ○
-
: Close, X: Open
