Autonics TK4L User Manual

6 Parameter Settings and Functions
72 © Copyright Reserved Autonics Co., Ltd.
6.3.3.1 Proportional Band Settings [PAR2 → H-P/C-P]
When PV (Present Value) is within the Proportional Band (P), the ON/OFF ratio needs to
be adjusted during the proportional period (T). The defined proportional control (time
proportional control) section is called as the proportional band.
Parameter Description
H-P
Heating Proportional Band
C-P
Cooling Proportional Band
Setting
Group
Parameter Setting Range
Factory
Default
Unit
PAR2
H-P
000.1
to
999.9
010.0
Temperature: ℃/℉
Analog: %
C-P
6.3.3.2 Integral Time Settings [PAR2 → H-I/C-I]
MVs from integral and proportional operation become the same when deviation is
consistent. The time taken for the two MVs to match is called the integral time.
Parameter Description
H-I
Heating Integral Time
C-I
Cooling Integral Time
Setting
Group
Parameter Setting Range
Factory
Default
Unit
PAR2
H-I
0000
to
9999
0000
Sec
C-I
 Integral control is not conducted if the integral time is set to 0.
 Setting the integral time too short can intensify Correction Movements
and cause hunting.
