Autonics TK4L User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 73
6.3.3.3 Derivative Time Settings [PAR2 → H-D/C-D]
In accordance with the deviation of the ramp, the time taken for the MV gained from
derivative operation to reach the MV gained from proportional control is called the
derivative time.
Parameter Description
H-D
Heating Derivative Time
C-D
Cooling Derivative Time
Setting
Group
Parameter Setting Range
Factory
Default
Unit
PAR2
H-D
0000
to
9999
0000
Sec
C-D
Derivative control is not conducted if the derivative time is set to 0.
6.3.3.4 Control Period Settings [PAR3 → H-T/C-T]
 If relay or SSR is used to output MV under proportional control, the output is on for a
fixed amount of time (within the control period, as a percentage of the MV) and then
remains off for the rest of the time. The preset period when output ON/OFF takes
place is called the proportional control period.
 Control with SSR output has a faster response than that of relay output. Therefore, by
configuring a shorter control period, more responsive temperature control is achieved.
Parameter Description
H-T
Heating Control Period
C-T
Cooling Control Period
Setting
Group
Parameter Setting Range Factory Default Unit
PAR3
H-T
00.1
to
120.0
Relay Output:
020.0
SSR Output:
002.0
Sec
C-T
If using heating and cooling control, configure each control period
separately for heating and cooling.
