Autronica Autroprime 2 - Page 94

Unit Configuration
Configuration Handbook, Autroprime Interactive Fire Detection System, 116-P-APRIME2-CONFIG/EGB, Rev. A, 2013-04-03,
Autronica Fire and Security AS
Page 94
From the External Interfaces Menu (5.13.1), perform the
following:
 Use the arrow down button to select MODBUS, then press Enter.
 Use the arrow down button to select Configure Command
Registers, then press Enter twice.
 Type the Start Address, then press Enter.
 To confirm the setting, press Enter once more.
5.13.5.4 Set Testbit to 0
This command is used for test purposes.
From the External Interfaces Menu (5.13.1), perform the
following:
 Use the arrow down button to select MODBUS, then press Enter.
 Use the arrow down button to select Set Testbit to 0, then press
Enter.
The following message will appear:
“Test finished”.


