# Task Notes
5 Marking the rack on page 26
6 Attaching rails to the server on
page 27
7 Attach the rails to the rack
8 Installing the server in the rack on
page 28
9 Replace the cabinet doors, if
necessary
See cabinet manufacturer's
documentation.
10 Turning on the server on
page 28
11 Troubleshoot the installation
Marking the rack
Prerequisites
The rack must be installed. If installing the server in a cabinet, then the doors must be removed.
You must allow 1 U (44 mm, or 1.75 in.) of vertical space for each server you install in the rack.
Rack cabinets that meet EIA-310 standards have an alternating pattern of three holes per rack
unit with center-to- center hole spacing (beginning at the top hole of a 1-U space) of 15.9 mm,
15.9 mm, and 12.7 mm (0.625 in., 0.625 in., and 0.5 in.) for the front and back vertical rails.
Rack cabinets may have round or square holes.
Note:
The vertical rails may be marked by horizontal lines and numbers in 1-U increments. If you
want, you can make a note of the number marking on the rack’s vertical rail. It is not
necessary to mark or place tape on the rack
Caution:
If you are installing more than one server, install the mounting rails so that the first server is
installed in the lowest available position in the rack. If you are installing a UPS in the same
rack as the server(s), install the UPS in the lowest available position in the rack and the
servers above it.
1. Place a mark (or tape) on the rack's front vertical rails where you want to locate the
bottom of the server.
Server installation and connectivity
26 Installing and Configuring Avaya Aura
™
System Platform April 2010
