6. Push the front latch (6) in all the way. See the preceding figure.
7. Repeat this procedure to install the other rail onto the rack.
8. Make sure that each front latch is fully engaged.
Next steps
Install the server in the rack.
Installing the server in the rack
Prerequisites
Attach rails to the rack.
1. Pull the slide rails forward (1) until they click, two times, into place. See the following
figure.
Server installation and connectivity
34 Installing and Configuring Avaya Aura
™
System Platform April 2010
