b. At the Communication Manager, set enable CF to y in the change media-gateway
screen.
c. In the SAT interface of the Communication Manager, enter enable announcement-
board.
d. The announcement files are copied from internal flash to the compact flash, and the
yellow CARD IN USE LED associated with the compact flash flashes.
4. Use the show platform mainboard CLI command to make sure the G430 is working
properly and to check the status of the compact flash and RAM memory.
For example:
MAINBOARD BOARD
------------------
Type : G430
Description : Avaya Inc., G430 Media Gateway
Serial Number : 08IS26191007
HW Vintage : 4
HW Suffix : F
FW Version : 29.18.0
No Fault Messages : No Fault Messages
RAM MEMORY SOCKET #1
------------------
Type : 512MB DDR SDRAM memory module
Serial Number : 0b2c7605
Manufacture Part Num : 64A6M64M8L-A06EWQU
Faults : No Fault Messages
COMPACT FLASH MEMORY
--------------------
Type : 2.0 GB
Serial Number : STI1M2a407200161753
Model Number : STI Flash 8.0.0
Faults : OK
Related links
Compact flash memory cards on page 82
Compact flash memory card removals
After installing a compact flash memory card, you may decide to remove it for one of several
reasons. The following sections provide instructions for safe removal of a compact flash memory
card in each possible scenario.
• Replacing a compact flash memory card with a different compact flash memory card on
page 84 holding a different set of announcements
• Replacing a compact flash memory card while retaining The current announcements on
page 84. You may wish to do this because the current compact flash memory card failed, or
you want to have two copies of the announcement files, or you want to use a faster compact
flash card.
•
Downgrading from a compact flash to internal flash memory on page 85
Related links
Compact flash memory cards on page 82
Field Replaceable Unit upgrades and replacements
