2. Navigate to Media Gateway downloads.
3. Locate the file names that match the files listed in your installation worksheet.
See
Sample software and firmware filenames on page 92 for sample firmware file names.
4. Double-click the file name of the file you want to download.
A File Download window appears.
Note:
Downloading files can occasionally add a [1] to the file name. Rename the file if
necessary.
5. Select Save this file to disk.
6. Save the file to directory on the TFTP server on the local LAN that was created for this
purpose.
See Setting up a TFTP server on page 91.
Result
Note:
If you are performing the upgrade using the Branch Gateway’s Command Line Interface (CLI),
you can place the upgrade files on an FTP server.
Related links
Upgrading firmware using the CLI through FTP/TFTP on page 88
Sample software and firmware filenames (continued) on page 92
Sample software and firmware filenames (continued)
Component File name Example
Branch Gateway Processors
Branch Gateway Processor gxxx_sw_21_11_0.bin
Branch Gateway Device Manager gxxx_emweb_1_0_7.bin
media modules
MM710 E1/T1 media module mm710v3.fdl
MM710B E1/T1 media module mm710v3.fdl
mm710bv47.fdl
MM711 Analog Port/Trunk media module (version 6 or earlier) mm711v16.fdl
MM711 Analog Port/Trunk media module (version 7) mm711h7v21.fdl
MM711 Analog Port/Trunk media module (version 20 or later) mm711h20v54.fdl
MM712 DCP media module mm712v14.fdl
MM714 Analog Port/Trunk media module mm714v5.fdl
MM714B Analog Port/Trunk media module mm714h10v93.fdl
Table continues…
Upgrading the Branch Gateway firmware
February 2017 Installation and Upgrades for the Avaya Branch Gateway G430 92
