Component File name Example
MM716 Analog Port/Trunk media module mm716v80.fdl
MM717 DCP media module mm717v3.fdl
MM720 BRI media module mm720v1.fdl
MM721 BRI media module mm721v1.fdl
MM722 BRI media module mm722v3.fdl
Related links
Downloading Branch Gateway firmware files to a local TFTP server on page 91
Installing firmware from the TFTP server on the S8300 Server
About this task
Instead of using a separately configured TFTP server on the LAN, you can use the TFTP server
capability of an S8300 Server to stage the firmware for upgrading the Branch Gateway.
Note:
You only have to do this procedure if you have not upgraded the S8300 first or if you did
upgrade it first and found that the gateway files on the Communication Manager CD were out of
date. Otherwise, when you upgrade the S8300, the files appear in the /tftpboot directory
automatically.
Procedure
1. Copy the individual firmware files to the /var/home/ftp/pub directory on the S8300 Server
using the Download Files web page on the S8300 Server.
2. Copy the files to the /tftpboot directory of the S8300 Server.
3. After copying the files to the /tftpboot directory, you can use the GIW to install the files to the
Branch Gateway or its media modules by specifying the S8300 Server’s IP address as the
TFTP server containing the new firmware files.
Related links
Upgrading firmware using the CLI through FTP/TFTP on page 88
Copying firmware files to the /tftpboot directory of an S8300 Server on page 93
Copying firmware files to the /tftpboot directory of an S8300 Server
Procedure
1. Use ssh craft@<ip address> to access the S8300 Server command line.
2. Address the password/challenge as required for access.
3. At the Linux prompt, type cd /var/home/ftp/pub and press Enter.
The Linux prompt reappears. The current directory has changed to /var/home/ftp/pub.
Branch Gateway firmware upgrades
February 2017 Installation and Upgrades for the Avaya Branch Gateway G430 93
