Avaya G430 - Page 211

• System capabilities
• Management address
Optional 802.1 TLVs
• VLAN name
• Port VLAN
Configuring LLDP
Procedure
1. Enable the LLDP agent globally using the set lldp system-control
command.
For example:
Gxxx-001(super)# set lldp system-control enable
Done!
The device’s global topology information, including all mandatory TLVs, is now
available to neighboring devices supporting LLDP.
2. Optionally, configure the administrative LLDP port status using the set port
lldp command.
The default value is rx-and-tx.
The device now sends LLDP TLVs and accepts LLDP TLVs from neighboring
devices supporting LLDP on the specified port.
For example:
Gxxx-001(super)# set port lldp 10/3 rx-and-tx
Done!
3. Optionally, configure additional TLVs transmission using the set port lldp
tlv command.
This allows you to advertise additional data about the device’s and port’s VLAN
information, VLANs, and system capabilities. Additional TLVs are disabled by
default.
For example:
Gxxx-001(super)# set port lldp tlv 10/3 enable all
Done!
The device now advertises all mandatory and optional TLVs to neighboring network
devices supporting LLDP.
4. If required, change any of the following timing parameters:
Switch Ethernet port configuration
Administering Avaya G430 Branch Gateway October 2013 211
