• The interval at which the device transmits LLDP frames, using the command
set lldp tx-interval. The default is 30 seconds.
• The value of TxHoldMultiplier, using the command set lldp tx-hold-
multiplier. TxHoldMultiplier is a multiplier on the interval configured by set
lldp tx-interval that determines the actual TTL value sent in an LLDP
frame. The default value is 30. The time-to-live value transmitted in TTL TLV
is expressed by: TTL = min(65535, TxInterval * TxHoldMultiplier).
• The minimal delay between successive LLDP frame transmissions, on each
port, using the command set lldp tx-delay. The default is 30 seconds.
• The delay from when a port is set to LLDP “disable” until re-initialization is
attempted, using the command set lldp re-init-delay. The default is
2 seconds.
5. Verify LLDP advertisements using the show lldp command.
Related topics:
Supported ports for LLDP on page 212
Supported ports for LLDP
You can configure only ports 10/3 and 10/4 to support LLDP.
Summary of LLDP configuration CLI commands
For more information about these commands, see the Avaya Branch Gateways G250 and
G350 CLI Reference.
For more information about these commands, see the Avaya Branch Gateway G430 CLI
Reference.
Command
Description
set lldp re-init-delay Set the delay from when a port is set to LLDP “disable”
until re-initialization is attempted
set lldp system-control Enable or disable the LLDP application globally per
device or stack
set lldp tx-delay Set the TxDelay, which is the minimal delay in
seconds between successive LLDP frame
transmissions, on each port
set lldp tx-hold-
multiplier
Set the TxHoldMultiplier, which is a multiplier
on the TxInterval that determines the actual TTL
value sent in an LLDP frame
Ethernet ports
212 Administering Avaya G430 Branch Gateway October 2013
