, Avg-Loss 0.0%
14
, Jitter 10mS #0
15
, Avg-Jitter 10mS
16
Echo-Cancellation:
Loss 49dB #0
17
, Len 32mS
RSVP:
Status Disabled, Failures 0
A few points to note:
• The QoS column in the show rtp sessions output has no asterisk (*), showing that
no metrics went over their event thresholds or average thresholds during the session [1]
• The QoS is described as “Ok” because there were no QoS problems [2]
• All average metric values are below the average thresholds [4] [5] [6] [8] [10] [12] [14] [16]
• All event counters are zero [3] [5] [7] [9] [11] [13] [15] [17]
A remote call from IP telephone to IP telephone
An unshuffled call is placed from IP telephone extension 2004 to IP telephone extension 2002
in the network described in
Four telephones in a sample network on page 373.
After the call is ended, the following commands are run:
//to display the RTP sessions:
Gxxx-001 (super)# show rtp sessions
ID QoS Start date and time End Time Type Destination
----- --- ------------------- -------- ------------- --------------
00011 2004-12-07,00:57:13 00:59:19 G711U 30.30.30.2
00012 * 2004-12-07,00:39:26 00:41:01 G711U 20.20.20.2
Monitoring applications
378 Administering Avaya G430 Branch Gateway October 2013
Comments? infodev@avaya.com
