Avaya G430 - Page 463

RIP distribution access lists on page 464
Configuring a distribution access list example on page 465
RIP limitations on page 465
Summary of RIP commands on page 466
RIPv1
RIPv1 is the original version of the RIP protocol. The RIPv1 protocol imposes some limitations
on the network design with regard to subnetting. When operating RIPv1, you must not configure
variable length subnetwork masks (VLMS). Each IP network must have a single mask, implying
that all subnetworks in a given IP network are of the same size. Also, when operating RIPv1,
you must not configure supernets. RIPv1 is defined in RFC 1058.
RIPv2
RIPv2 is a newer version of the RIP routing protocol. RIPv2 solves some of the problems
associated with RIPv1. The most important change in RIPv2 is the addition of a subnetwork
mask field which allows RIPv2 to support variable length subnetworks. RIPv2 also includes
an authentication mechanism similar to the one used in OSPF. RIPv2 is defined in RFC 2453.
For more information, see
RIPv1 vs. RIPv2 on page 463.
RIPv1 vs. RIPv2
RIPv1 RIPv2
Broadcast addressing Multicast addressing
Timer-based – updated every 30 seconds Timer-based – updated every 30 seconds
Fixed subnetwork masks VLSM support – subnet information transmitted
No security Security (authentication)
No provision for external protocols Provision for EGP/BGP (Route tag)
The router
Administering Avaya G430 Branch Gateway October 2013 463
